Zoy H910 Hard-Shell Pressurized Chamber System

Zoy H910 Hard-Shell Pressurized Chamber System

Product Overview

The Zoy H910 is a hard-shell, pressurized equipment enclosure designed for controlled atmospheric operation in professional, industrial, and research facility environments. The system features a reinforced structural design, dual control interfaces, and compatibility with external gas supply systems for regulated internal conditions.

This product is sold as equipment only. No medical, therapeutic, or health claims are made or implied.

---

Chamber Construction & Design

Chamber Type: Hard-shell pressurized enclosure
Orientation: Horizontal enclosure configuration
Material: Aluminum alloy
Viewing Window: Polycarbonate
Chamber Dimensions: Ø900 mm × 2250 mm
Structural Design: Reinforced frame surrounding viewing window
Unit Weight: Approx. 200 kg

---

Pressure & Operation

Operating Pressure Capability: Adjustable, up to 2.0 ATA
Compression Pressure Range: 0–200 kPa

Pressure Monitoring Systems:
• Internal pressure gauge
• External pressure gauge

Manual Pressure Control Valve: Included
Emergency Stop Function: Included

---

Control & Interface Systems

Control Interfaces:
• Internal control interface
• External control interface

Display: 7-inch LCD touchscreen

Displayed System Parameters:
• Chamber pressure
• Gas supply status
• System operation time
• Internal atmospheric readings

Communication System:
• Two-way intercom for operational coordination

---

Gas Supply System

Gas Supply Type: PSA-based external gas generation system
Maximum Flow Capacity: Up to 20 L/min
Output Concentration Range: 90%–96%
Output Pressure Range: 130–700 kPa

Gas supply specifications describe equipment capacity only.

---

Internal Gas Management System

Internal Gas Circulation System

• One-way valve configuration separating intake and exhaust pathways
• Exhaust routed externally from the enclosure
• Designed to maintain stable internal atmospheric conditions

---

Integrated Support System (HMO-20)

Multi-function support unit combining compression, gas generation, and cooling.

Air Compression Module:
• Oil-free design
• Dual-set compressor configuration

Gas Generation Module:
• 20 L/min capacity

Cooling Module:
• Integrated high-performance cooling system

Control System: Siemens PLC
Interface: Color touchscreen for system monitoring

---

Electrical & Environmental Specifications

Power Consumption: 1800 W
Voltage: AC 220V (±10%), 50/60 Hz
Noise Level: ≤ 60 dB

Operating Environment:
• Temperature: -10°C to 40°C
• Humidity: 20%–85% RH

Storage Temperature: -20°C to 60°C

---

Disclaimer

Important Notice

This product is sold as professional pressurized equipment only.
No medical, therapeutic, recovery, or health claims are made or implied.
This product is not intended to diagnose, treat, cure, or prevent any condition.
Buyers are responsible for compliance with all applicable local regulations and intended use requirements.
